SCADA for Heat Control Units

In today’s world, optimized energy use and energy conservation have become a pressing challenge. There are many areas within a city that actively consume various kinds of energy.

A specialized organization analyzed energy consumption and concluded that there is over consumption of energy in a city due to improper regulation of thermal energy supply depending on the outside temperature.

So, they arrived at the conclusion that if the functioning of the thermal equipment is optimized, we would be able to save up to 30% energy for heating.
download pdf

Challenge

We needed to develop a remote data acquisition system with heat metering and regulation devices. Based on the data acquired and energy consumption analysis of its consumption indicators in certain houses, was to be adjusted the work of the regulation equipment.

Solution

  • We built a data acquisition system using interface Ethernet converters. Metering and regulation devices are connected to the converters. We made this decision because heat metering and regulation devices are located in the same houses where, in most success-stories, data communication networks are installed.

  • We developed a software package that consists of a data acquisition and long storage system, with a user interface accessible via web.

Features

8867D4E2-908D-4BC2-93D9-91DA20E11936Created with sketchtool.

Constant control of heat metering and regulation equipment

2BFC1661-D29C-4E26-A49F-576A40ECF2C9Created with sketchtool.

Access to user interface via the web

19763873-482C-4625-AC06-BFAF97504811Created with sketchtool.

Possibility to adjust the work of equipment

5BB62B8B-8D04-4173-82EE-993FA94F8E20Created with sketchtool.

Possibility to acquire data remotely and provide long-term storage

Technology
used

Danfoss ECL
Landis+Gyr Ultraheat @WR
Advantech 4000
Web-based SCADA
